3TF50 World Series Power Contactor

Short Description:

3TF50, Nofuel, direct replacement contactors for Siemens World Series 3TF50, 3 pole, 3 phase, 110Amp, 600Volt, 50HP @ 230V, 100HP @ 460V, 125HP @ 575V, complete with 110/120VAC coil, 2NO/2NC aux contact installed, AC contactor


  • FOB Price: US $5 - 499 / Piece
  • Supply Ability: 5000 Pcs per Month
  • Payment Terms: L/C, D/P, T/T, Paypal
  • Control voltage: 24V 48V 72V 110V 230V 240V 380V 440V 480V
  • Brand : Nofuel
  • Product Detail

    Product Tags

    Application

    The contactor is a straight motion mechanism having double-breaking contacts. The auxiliary contacts are arranged 2NO.2NC at most, it is employed the flexible locking connection between the contact support and core , three are no arcisolated panle in the le ≤ 22A contactors, in the le ≤ 32A contactors, there are moulded are-chute with arc-isolated panel. Because all contacts are made of high nonfusibility and against corrosion silver alloy. All series products can be mounted by screws, le ≤ 32A contactor also by installation rail .

    Model Part Number Amp  HP@230V HP@460V HP@575V Weight Lbs
    3TB-40 3TB40 9 3 5 7.5 0.20
    3TB-41 3TB41 12 3 7.5 10 0.20
    3TB-42 3TB42 16 3 10 10 0.20
    3TB-43 3TB43 22 7.5 15 20 0.20
    3TB-44 3TB44 32 10 25 30 0.20
    3TF-40 3TF4022 9 3 5 7.5 0.20
    3TF-41 3TF4122 12 3 7.5 10 0.20
    3TF-42 3TF4222 16 5 10 10 0.22
    3TF-43 3TF4322 22 7.5 15 20 0.22
    3TF-44 3TF4422 32 10 25 30 0.36
    3TF-45 3TF4522 38 15 28 30 0.36
    3TF-46 3TF4622 45 20 40 50 0.73
    3TF-47 3TF4722 63 25 50 60 0.73
    3TF-48 3TF4822 75 30 60 75 1.14
    3TF-49 3TF4922 85 40 75 100 1.14
    3TF-50 3TF5022 110 50 100 125 1.59
    3TF-51 3TF5122 140 60 110 150 1.59
    3TF-52 3TF5222 170 60 125 150 2.27
    3TF-53 3TF5322 205 75 150 200 2.27
    3TF-54 3TF5422 250 100 200 250 2.91
    3TF-55 3TF5522 300 125 250 300 2.91
    3TF-56 3TF5622 400 150 300 400 3.95
    3TF-57 3TF5722 475 200 400 500 3.95

    3TF World Series
    in IEC standard

    Rated operating Current AC-380V

    Rated voltage

    Standard power ratings of 3-phase

    Weight







    220/230V

    380/400V

    480V/500V

    690/660V





    (A)

    (V)

    KW

    KW

    KW

    KW

    Kg

    3TB40

    9

    690

    2.4

    4

    5.5

    5.5

    0.43

    3TB41

    12

    690

    3.3

    5.5

    7.5

    7.5

    0.43

    3TB42

    16

    690

    4

    7.5

    10

    11

    0.43

    3TB43

    22

    690

    6.1

    11

    11

    11

    0.43

    3TB44

    32

    690

    8.5

    15

    21

    23

    0.43

    3TF40

    9

    690

    2.4

    4

    5.5

    5.5

    0.43

    3TF41

    12

    690

    3.3

    5.5

    7.5

    7.5

    0.43

    3TF42

    16

    690

    4

    7.5

    10

    11

    0.49

    3TF43

    22

    690

    6.1

    11

    11

    11

    0.49

    3TF44

    32

    690

    8.5

    15

    21

    23

    0.8

    3TF45

    38

    690

    11

    18.5

    25

    23

    0.8

    3TF46

    45

    690

    15

    22

    30

    39

    1.6

    3TF47

    63

    690

    18.5

    30

    41

    55

    1.6

    3TF48

    75

    690

    22

    37

    50

    67

    2.5

    3TF49

    85

    690

    26

    45

    39

    67

    2.5

    3TF50

    110

    690

    37

    55

    76

    100

    3.5

    3TF51

    140

    690

    43

    75

    98

    100

    3.5

    3TF52

    170

    690

    55

    90

    118

    156

    5

    3TF53

    205

    690

    64

    110

    145

    156

    5

    3TF54

    250

    690

    78

    132

    178

    235

    6.4

    3TF55

    300

    690

    93

    160

    210

    235

    6.4

    3TF56

    400

    690

    125

    200

    284

    375

    8.7

    3TF57

    475

    690

    145

    250

    329

    375

    8.7

    3TF3-0X–
    3TF4-0X—
    3TF5-0X–
    50HZ 60HZ 50/60HZ
    24V B0 24V C1 24V C2
    48V H0 110V G1 42V D2
    110V F0 120V K1 110V G2
    220V M0 208V M1 120V K2
    230V P0 220V N1 208V M2
    240V U0 230V L1 220V N2
    380V Q0 240V P1 240V P2
    415V R0 440V R1 440V R2
    500V S0 575V S1 575V S2
