LC1-K06 TeSys K mini contactor

Short Description:

LC1-K series AC contactor is suitable for use in the circuits up to the rated and frequent starting, controlling the AC motors. The addtion of auxiliary contact group to the contactor, combined with the proper thermal relay, can act to protect the circuit bound to overload.

TeSys K Compact contactors up to 7.5kW 400/415V  with a wide variety of coil voltage and terminal connection options.


  • FOB Price: US $5 - 499 / Piece
  • Supply Ability: 5000 Pcs per Month
  • Payment Terms: L/C, D/P, T/T, Paypal
  • Control voltage: 24V 48V 72V 110V 230V 240V 380V 440V 480V
  • Brand : Nofuel
  • Product Detail

    Product Tags



    Type

    Rated working current A(380V)   220V

    AC-3 use group control power (kW)

    380V~415V 440~500V

      660V  Contact data(1)

    LC1-K06

    6

    1.5

    2.2

    3

    3

    3P+NO 3P+NC

    LC1-K09

    9

    2.2

    4

    4

    4

    3P+NO 3P+NC

    LC1-K12

    12

    3

    3

    5

    5

    3P+NO 3P+NC
    Specifications LC1-K06 LC1-K09 LC1-K12
    Use group under AC-3

    6

    9

    12

    Rated working current(le)A

    5

    7.5

    10

    Conventional  thermal current(lth)A

    16

    20

    20

    Rated working voltage(Ue)V

    380 660

    Rated insullation voltage(Ui)V

    690

     AC-3(6le le) Electrical life(time)

    0.5×106

      Operation frequency h-1

    1200

     AC-3(6le le) Electrical life(time)

    10×104

      Operation frequency h-1

    300

    Mecnical life  Auxiliary contact  Conventional  thermal current

    3×106

    6A

       Electrical  life(time) AC-15(360VA)

    0.5×106

        DC-13(33W)
           Coil specifications  Rated control voltage(Us) AC: 12, 24, 45, 110, 220, 380
        DC: 12, 24, 45, 110, 220
      Pick-up voltage AC: 0.85~1.1Us   DC: 0.85~1.1Us
      Resleasing voltage AC: 0.2~0.75Us   DC: 0.2~0.75Us
       Coil power VA Pick-up

    40

        Fotain

    4

      Consumption

    1.2W

      Pick-up time

    6~18ms

      Releasing timePower factor

    5~23ms

    Making 0.8 Breaking 0.3

    AC operating coils

    Maximum Horsepower Ratings Maximum Current  Type of Connection Auxiliary Contacts  Catalog
    Number
    1 Ø 3 Ø Inductive AC3
    Amperes
    Resistive AC1
    Amperes
    115 V hp 230 V hp 200 V hp 230 V hp 460 V hp 575 V hp N.O. N.C.
     0.5  1.5  1.5  1.5  3  3  6  15  Screw-clamp 1 1 LC1K0610
    LC1K0601
    0.5 1.5 2 3 5 5 9 20 Screw-clamp 1 1 LC1K0910
    LC1K0901
    0.5 1.5 3 3 7.5 10 12 20 Screw-clamp 1 1 LC1K1210
    LC1K1201

    Coil voltage codes for AC contactors

    Volts AC 50/60 Hz 12

    24

    42 48 110 120 127 200/
    208
    220/
    230
    230 230/
    240
    277 380/
    400
    400/
    415
    440 480
    Code J7

    B7

    D7 E7 F7 G7 FC7 L7 M7 P7 U7 UE7 Q7 N7 R7 T7

     DC operating coils

    0.5 1.5 1.5 1.5 3 3 6 15 Screw-clamp 1 1 LP1K0610 abLP1K0601 ab
    0.5 1.5 2 3 5 5 9 20 Screw-clamp 1 1 LP1K0910 abLP1K0901 ab
    0.5 1.5 3 3 7.5 10 12 20 Screw-clamp 1 1 LP1K1210 abLP1K1201 ab

    Overload relays for 3-Pole contactors with screw-clamp terminals

    Class 10, Relay setting range–A Catalog Number
    0.1 to 0.16 LR2K0301 LR2K overload relays:

    • AC or DC protection
    • Ambient compensated bimetallic
    • Class 10
    • Single phase sensitivity
    • Manual or auto reset
    • Full load current dial
    0.16 to 0.23 LR2K0302
    0.23 to 0.36 LR2K0303
    0.36 to 0.54 LR2K0304
    0.54 to 0.8 LR2K0305
    0.8 to 1.2 LR2K0306
    1.2 to 1.8 LR2K0307
    1.8 to 2.6 LR2K0308
    2.6 to 3.7 LR2K0310
    3.8 to 5.5 LR2K0312
    5.5 to 8 LR2K0314
    8 to 11.5 LR2K0316
    10 to 14 LR2K0321
