Compact NSX MCCB

Short Description:

Experience the superior quality of the Nofuel Series Compact NSX Molded Case Circuit Breaker.  The Series circuit breaker is ideal for panelboards, switchboards, motor control centers, and busway applications. Choose from a premier selection of trip units including thermal magnetic, electronic, and magnetic only switches. Available for systems up to 600 VAC or 250 VDC with current ratings up to 630A.




  • FOB Price: US $5 - 499 / Piece
  • Supply Ability: 5000 Pcs per Month
  • Payment Terms: L/C, D/P, T/T, Paypal
  • Control voltage: 24V 48V 72V 110V 230V 240V 380V 440V 480V
  • Brand : Nofuel
  • Product Detail

    Product Tags

    Typpe      NSX100      NSX250       NSX400      NSX630
    Rated current In(A) 16…100A 12…250A 250…400A 400…630A
    Number of poles 3

    1

    3 3 3
    Rated voltage Ue(V) AC-380V-69V DC250
    Rated insulation Voltage Ui(V) AC690V
        Short-circuit Interrupting capacity Icu/Ics      AC 690V - 14/7 35/18 35/18
    500V - 14/7 35/18 35/18
    440V 20/10 50/25 100/75 100/75
    415V 25/13 70/70 100/75 100/75
    380V 25/13 70/70 100/75 100/75
    230V 65//33 100/100 200/150 200/150
    DC 250V 10/5 20/10 20/10 20/10
    Dimensions(mm)     a 77

    35

    105 140 210
    b 124 153 258 275
    c 67 86 104 111
    ca 77 108 138 168
    Weight(kg) 1

    0.7

    2.4 6.1 9.4
    Electrical-operation device
    Automatic tripping device Thermal-magnetic Thermal-magnetic Thermal-magnetic Thermal-magnetic
